ASTM F67 GR5 Titanium Bar
1.ASTM F67 GR5 Titanium Bar is a high-strength, corrosion-resistant alloy that is commonly used in the aerospace, medical, and marine industries.
2.It is made from a blend of 90% titanium, 6% aluminum, and 4% vanadium, which provides its superior mechanical properties.
3.This grade of titanium bar is known for its low weight, high strength, and excellent biocompatibility, making it an ideal choice for medical implants and surgical instruments.
Product Introduction
Chemical Composition Of Titanium Grades 5
|
Grade |
Nominal chemical composition |
Main ingredients(%) |
Impurities, not greater than(%) |
|||||||
|
Ti |
Other main ingredients |
Fe |
C |
N |
H |
O |
Other elements |
|||
|
Single |
Total |
|||||||||
|
GR5 |
Ti-6Al-4V |
Allowance |
Al:5.5~6.75 V:3.5~4.5 |
0.30 |
0.08 |
0.05 |
0.015 |
0.20 |
0.10 |
0.40 |
Chemical Composition Of Titanium Grades 5
|
Grade |
Mechanical properties at room temperature, not less than |
|||
|
Tensile strength Rm/Mpa |
Elongation strength Rp0.2/Mpa |
Section elongation A/% |
Section shrinkage Z/% |
|
|
GR5 |
895 |
825 |
10 |
25 |
ASTM F67 Standard Requirements For Titanium Bar
1. Chemical Composition: The titanium bar should conform to the chemical compositions specified in the ASTM F67 standard.
2. Mechanical Properties: The material should have a minimum tensile strength and yield strength as specified in the standard. The properties should be consistent throughout the length of the bar.
3. Dimensions: The dimensions such as diameter, length, and straightness should be within the tolerance limits specified in the standard.
4. Surface Quality: The bar surface should be free from defects such as cracks, pits, scratches, and other surface imperfections that could affect the performance of the material.
5. Sampling and Testing: The titanium bar should be sampled and tested according to the ASTM F67 standard procedures before acceptance.
6. Certification: The manufacturer must provide a certificate of compliance with the ASTM F67 standard, including the chemical composition, mechanical properties, and other requirements specified in the standard.
7. Packaging and Marking: The titanium bar should be packaged and marked to prevent damage and identify the material, including the ASTM F67 standard designation.
