EN 10253 GR3 Titanium Elbow
1.EN 10253 GR3 Titanium Elbow is a type of pipe fitting that is used to connect two pipes of different angles.
2.It is made of grade 3 titanium, which is a corrosion-resistant material that is widely used in various industries.
3.This elbow conforms to the European standard EN 10253, which ensures its quality and safety for use in applications where high temperatures and pressures are involved.
Product Introduction
Chemical Composition Of Titanium Grades 3
|
Grade |
Nominal chemical composition |
Main ingredients(%) |
Impurities, not greater than(%) |
|||||||
|
Ti |
Other main ingredients |
Fe |
C |
N |
H |
O |
Other elements |
|||
|
Single |
Total |
|||||||||
|
GR3 |
Industrial pure titanium |
Allowance |
|
0.30 |
0.08 |
0.05 |
0.015 |
0.35 |
0.10 |
0.40 |
Mechanical Properties Of Titanium Grades 3
|
Grade |
Mechanical properties at room temperature, not less than |
|||
|
Tensile strength Rm/Mpa |
Elongation strength Rp0.2/Mpa |
Section elongation A/% |
Section shrinkage Z/% |
|
|
GR3 |
450 |
380 |
18 |
30 |
Processing Process Of EN 10253 GR3 Titanium Elbow
1. Selection of Raw Materials: The first step is the procurement of high-quality raw materials like grade 3 titanium. The material must meet the EN 10253 standards.
2. Cutting and Shaping: The raw material is cut and shaped to the required dimensions using a saw, lathe machine, or a CNC machine.
3. Heating and Forming: The next step is to heat the titanium to a temperature of 800-1000 degrees Celsius and then form it to the desired shape using a hydraulic or mechanical press.
4. Annealing: After forming, the elbow is subjected to an annealing process where it is heated to a specific temperature to soften the metal and improve its ductility.
5. Welding: The formed elbow is then welded using a Tungsten Inert Gas welding process to join the two ends.
6. Surface Treatment: Lastly, the elbow is polished to a smooth finish and undergoes surface treatment to prevent corrosion, improve its resistance to wear and tear, and ensure a longer lifespan.
