What Are The Design Features Of Titanium Heat Exchangers?
Titanium heat exchanger is a new type of high-efficiency heat exchanger, which consists of a series of titanium sheets with a corrugated shape. A thin rectangular channel is formed between the different titanium plates, and heat is exchanged through the half plates.
Titanium heat exchanger
It is an ideal liquid-liquid and liquid-vapor heat exchange equipment. It has the characteristics of high heat transfer efficiency, small heat loss, compact and light structure, small footprint, convenient installation and cleaning, wide application and long service life. Under the same pressure loss, the heat transfer coefficient is 3-50% higher than that of the tubular heat exchanger, accounting for one-third of the area of the tubular heat exchanger, and the heat recovery rate can reach 90%.
The removable titanium heat exchanger is made of many punched wave titanium plates sealed with gaskets at some intervals, and overlapped with frames and compression screws. The four corner holes of the plates and gaskets form fluid distribution and collection pipes. At the same time, the cold and hot fluids are reasonably separated so that they flow in the channels on both sides of each titanium plate and exchange heat through the titanium plates.
Design Features of Titanium Heat Exchanger
1. Energy saving: the heat transfer coefficient is 3000-4500kcal/m2°C/h, which is 30-50% of that of the shell-and-tube heat exchanger.
2. Compact structure: The heat exchanger is compactly arranged. Compared with other types of heat exchangers, it occupies a smaller area and space. The heat exchanger with the same heat exchange area is only 1/1 of the shell-and-tube heat exchanger. 5.
3. Easy to clean and disassemble: The titanium heat exchanger clamps the splint through clamping bolts, which is convenient for disassembly and assembly, and can be opened and cleaned at will. At the same time, due to the smooth surface of the plate and the high degree of turbulence, it is not easy to scale.
4. Long service life: It is made of titanium alloy plate, which can resist a variety of corrosive media. The rubber pad can be replaced at will, and it is easy to disassemble and maintain.
5. Strong adaptability: This heat exchanger is an independent component, which can freely increase or decrease the flow rate according to the needs, and has various forms, which are suitable for various requirements of different processes.
6. No liquid leakage. The sealing groove of the titanium heat exchanger is provided with a leakage channel, and various media will not collude, and even if a leakage occurs, the media will always be discharged outward.
